174
Need help planning your system or advice on LED lighting? Email liontech@lionpic.co.uk
Add Cobra Suspenders & hooks, see p.171
6176 Screws 4 x 40mm
6177 Wall plugs 6 x 35mm
5822 Brass Fixing Buttons 5093 Brass Joiner
6183 End Cap White
6184 End Cap Silver Grey
6336 Corner joiner White
6337 Corner joiner Silver Grey
pk10 £1.02 pk10 £1.12 10 £4.38
Multirail Accessories 6176
5822
6337
2 1 1 1 1
£2.11 £0.71 £0.71 £1.36 £1.36
6336
6183
6184
LED 3.5
4 15 25
9242
LED
<4W
20W
3.4W 170lm neutral white 3000K standard - diffuse 30° spotlight MR11-GU4.0 £15.65
Multirail Combined picture hanging and lighting
STAS multirail is a unique hanging rail with integrated 12v voltage power supply, which means you can click a spotlight arm into the rail exactly where you want to light each picture. LED spotlights make the systme very energy-efficient.
TÜV Nederland QA
Choose transformer according to choice of spotlight and size of installation
Choose spotlight arms and spotlights according to height of installation and size of artworks
•
•
•
Choice of white or silver Multirail, fits to wall min 20mm from ceiling. Rail can be cut to length. Joiners, end and corner caps available.
Use 5822 Brass Fixing Buttons every 300mm approx.
Join each section of rail with a joiner and electrical connector
10139
10141
6125
•
•
•
Add Cobra suspenders and Zipper or SmartSpring hooks See p.171.
45kg per m
8mm
See PUB014 Multirail user info
See PUB029 Multirail technical info
Transformers 220v/12v
Multirail
10141 STAS Multirail WHITE
10142 STAS Multirail WHITE
10139 STAS Multirail SILVER
10140 STAS Multirail SILVER
6124 Elec Connector - Straight
6125 Elec Connector - Corner
1 x 2m £40.80 1 x 3m £61.14 1 x 2m £40.80 1 x 3m £61.14
£2.10 £2.94
32mm
6124
Your choice of transformer depends on:
• Whether you’re using LED or halogen spotlights
• How many metres of rail you’re installing
• The number of spotlights you need
9243
Transformers have 3m cable, Multirail connector and Euro plug. UK adaptor required.
If in any doubt, contact an electrician.
9244
9243 Multirail Transformer 18w
9244 Multirail Transformer 60w
9245 Multirail Transformer 96w
Each transformer powers up to 16m of rail
LED 4W
3 12 20
9245
£19.54 £43.25 £50.16
Spotlight Arms with Bulb Holder
Choose 700mm lighting arms for larger pictures or for rails fitted above 2.7m. Add a bulb with a 95° beam for maximum illumination spread.
6174
6174 6121 6175 6122
Arm White Arm Chrome Arm White Arm Chrome
500mm 500mm 700mm 700mm
£25.01 £25.01 £30.06 £30.06
6175
LED Spotlight Bulbs
9564 9242
9564
9242
6121
6122
Power
Output equivalent Max. consumption Light intensity Light colour Colour temp. Light beam
Beam angle Socket
9564
STASLED3.5w/95° STASPowerLED4w/30°
LED
3.5W
20W
3.5W 200lm warm white 2700K standard - diffuse 95° flood MR11-GU4.0 £16.54
Emits a wide beam of light suitable for large paintings.
The closed housing avoids light spill at the back.
Ordering information on p.193
8
2
s
7
2
B
m
4
-
P
e
-
0
t
i
s
0
c
y
S
t
g
u
n
i
g
r
e
H
a
n
STAS Picture Hanging & Display
